STA1102R 3 Gbps, 2 differential-pair channel eSATA signal re-driver

The STA1102R is a serial data signal re-driver. It integrates two differential-pair channels suitable for eSATA signals up to a 3 Gbps data rate, in compliance with the SATA rev 2.6 specification.

An input detector is available at each channel, which constantly monitors the input signal level for output squelch functionality. If the detected differential input is below a defined threshold, the output is biased to the common mode voltage.

High-speed data paths and the flow-through pinout minimize internal device jitter and simplify board layout. The integrated input equalizer improves signal integrity at the receiver due to effects from lossy cables. A 1-bit adjustable pre-emphasis is also integrated to drive the transmitter outputs over long PCB track lengths.

The device can be set to a low-power mode by disabling the output current drivers through the EN pin

技术特性

Supports eSATA data rate of 1.5 Gbps and 3 Gbps
Supports complete eSATA bus of two 2-wire differential-pair channels
Squelch detector for validity of input differential signal
Single operating supply (VCC) range of 3.3 V ± 10%
Low power mode
100 Ω CML I/Os
eSATA hot-plug capable
Low capacitance on all channels
1-bit input equalizer regenerates the receiver attenuated signal
1-bit adjustable pre-emphasis and driver to drive the transmitter outputs over long PCB track lengths
Low output skew and jitter
Low ground bounce
Available in QFN20 (4 x 4 mm) package footprint with flow-through pinout
-40 °C to 85 °C operating temperature range

功能框图

STA1102R 订购信息

订购型号	产品状态	美金价格	数量	封装	包装形式	温度范围	材料声明
STA1102RUTR	Active		1000	VFQFPN 20 4x4x0.8	Tape And Reel		STA1102RUTR

DATASHEET

描述	版本	大小
STA1102R : DS6521: 3 Gbps, 2 differential-pair channel eSATA signal re-driver	4	251KB
