STM32F101xC、STM32F101xD和STM32F101xE基本型系列产品集成了工作频率为36MHz的高性能ARM ®Cortex™-M3 32位RISC内核、高速嵌入式存储器(Flash存储器和SRAM的容量分别高达512K字节和48K字节)，和大量连至2条APB总线的增强型I/O与外设。 所有型号的产品均带有1个12位ADC和4个16位通用定时器，以及标准与高级通信接口：22个I²C、3个SPI和5个USART。
这些特性让STM32F101xx大容量基本型微控制器系列成为各种应用的理想之选，例如医疗和手持式设备、PC和游戏外设、GPS平台、工业应用、PLC、打印机、扫描仪、警报系统和视频电话。
技术特性
- 内核：ARM 32位Cortex™-M3 CPU
- 36 MHz maximum frequency,1.25 DMIPS/MHz (Dhrystone 2.1) performance
- Single-cycle multiplication and hardware division
- 存储器
- 256 to 512 Kbytes of Flash memory
- Flexible static memory controller with 4 Chip Select. Supports Compact Flash, SRAM, PSRAM, NOR and NAND memories
- LCD parallel interface, 8080/6800 modes
- 时钟、复位和电源管理
- 2.0 to 3.6 V application supply and I/Os
- POR, PDR, and programmable voltage detector (PVD)
- 4-to-16 MHz crystal oscillator
- Internal 8 MHz factory-trimmed RC
- Internal 40 kHz RC with calibration capability
- 32 kHz oscillator for RTC with calibration
- 低功耗
- Sleep, Stop and Standby modes
- VBAT supply for RTC and backup registers
- 1个12位、1μs A/D转换器(多达16通道)
- Conversion range: 0 to 3.6 V
- 2个12位D/A转换器
- DMA
- 12-channel DMA controller
- Peripherals supported: timers, ADC, DAC, SPIs, I²Cs and USARTs
- 多达112个高速I/O端口
- 51/80/112 I/Os, all mappable on 16 external interrupt vectors and almost all 5 V-tolerant
- 调试模式
- Serial wire debug (SWD) & JTAG interfaces
- Cortex-M3 Embedded Trace Macrocell™
- 多达9个定时器
- Up to four 16-bit timers, each with up to 4 IC/OC/PWM or pulse counters
- 2 × watchdog timers (Independent and Window)
- SysTick timer: a 24-bit downcounter
- 2 × 16-bit basic timers to drive the DAC
- 多达10个通信接口
- Up to 2 x I²C interfaces (SMBus/PMBus)
- Up to 5 USARTs (ISO 7816 interface, LIN, IrDA capability, modem control)
- CRC计算单元、96位唯一ID
- ECOPACK®封装
|
功能框图
 |
