SAK-TC1793F-512F270EF AB 数据手册DataSheet 下载
The TC1793 is one of three premium derivatives of the AUDO MAX family. It’s 270MHz award-winning TriCoreTM CPU provides high-end microcontroller performance combined with sophisticated DSP capabilities and dedicated safety features.
技术特性Summary of Features:
| 应用领域Target Applications:
|
订购型号
| Sales Product Name | OPN | Product Status | Order online | Package Name | Totally lead-free | Halo-free | RoHS | Packing Size | Packing Type | Moisture Level |
|---|---|---|---|---|---|---|---|---|---|---|
| SAK-TC1793F-512F270EF AB | TC1793F512F270EFABKXUMA1 | not for new design | PG-BGA-416 | yes | yes | yes | 500 | TAPE & REEL | 3 | |
| TC1793F512F270EFABKXUMA2 | in production | PG-BGA-416 | yes | yes | yes | 500 | TAPE & REEL | 3 |
