STCD1020 Clock Distribution Circuit
The STCD1020, STCD1030 and STCD1040 are 2, 3 or 4 outputs unity gain clock distribution circuits, which are used to provide a common frequency clock to multimode mobile RF applications. It can also be used for those baseband peripheral applications in a mobile phone such as WLAN, Bluetooth, GPS and DVB-H as a clock reference. The STCD1020, STCD1030 and STCD1040 isolate each device driven by their clock outputs and minimize interference between the devices. Each of the clock buffers can be disabled to lower the power consumption if the connected device does not need the clock. The STCD1020, STCD1030 and STCD1040 accept commonly used mobile master clock frequencies ranging from 10 MHz to 52 MHz.
The STCD1020, STCD1030 and STCD1040 are available in 2 mm x 2 mm 8-lead, 2 mm x 2.5 mm 10-lead and 2 mm x 3 mm 12-lead TDFN packages and can be operated with a single 2.8 V (or 1.8 V) supply. The operating temperature is –40 °C to +85 °C.
技术特性
- 2, 3 or 4 outputs buffered clock distribution
- Single-ended sine wave or square wave clock input and output
- Individual clock enable for each output
- Lower fan-out on clock source
- No AC coupling capacitor needed at the input
- Ultra-low phase noise and standby current
- 2.5 V to 3.6 V supply voltage
- 10 pF typical load driving capability
- Available in TDFN packages
- STCD1020 - 8-lead (2 mm x 2 mm)
- STCD1030 - 10-lead (2 mm x 2.5 mm)
- STCD1040 - 12-lead (2 mm x 3 mm)
- Operating temperature : –40 °C to 85 °C
|
功能框图
 |
STCD1020 订购信息
| 订购型号 |
产品状态 |
美金价格 |
数量 |
封装 |
包装形式 |
温度范围 |
材料声明 |
| STCD1020RDG6F |
Active |
|
|
DFN8 2x1x0.55 |
Tape And Reel |
|
STCD1020RDG6F |
DATASHEET
| 描述 |
版本 |
大小 |
| STCD1020 : DS5426: 多通道时钟分配电路 |
6 |
2272KB |
APPLICATION NOTES
| 描述 |
版本 |
大小 |
| AN2760: Using clock distribution circuits in smart phone system design |
1 |
211KB |
