TM90CZ-24 HIGH VOLTAGE HIGH POWER GENERAL USE INSULATED TYPE

技术特性 Features
  • IT (AV) Average on-state current ............ 90A
  • VRRM Repetitive peak reverse voltage........ 1200/1600V
  • VDRM Repetitive peak off-state voltage........ 1200/1600V
  • DOUBLE ARMS
  • Insulated Type
  • UL Recognized
    Yellow Card No. E80276 (N)
    File No. E80271
应用领域 APPLICATION

DC motor control, NC equipment, AC motor control, Contactless switches, Electric furnace temperature control, Light dimmers

TM90CZ-24 产品实物图

TM90CZ-24 产品实物图

订购信息 Ordering Information
  • TM90CZ-24
  • TM90DZ-24
  • TM90CZ-2H
  • TM90DZ-2H
外观尺寸图 Outline Drawing

TM90CZ-24 外观尺寸图


应用技术支持与电子电路设计开发资源下载 版本信息 大小
TM90CZ-24 数据资料DataSheet下载:PDF Rev.V2 2 页
