LUPA1300-2:High Speed CMOS Image Sensor
LUPA1300-2 is an integrated SXGA high speed, high sensitivity CMOS image sensor. This sensor targets high speed machine vision and industrial monitoring applications. The LUPA1300-2 sensor runs at 500 fps and has triggered and pipelined shutter modes. It packs 24 parallel 10-bit A/D converters with an aggregate conversion rate of 740 MSPS. On-chip digital column FPN correction enables the sensor to output ready to use image data for most applications.
技术特性
- Integrated digital column FPN correction
- Runs at 500 fps and has triggered and pipelined shutter modes
- 24 parallel 10-bit A/D converters with an aggregate conversion rate of 740 MSPS
- Industrial monitoring
|
封装图 MARKING DIAGRAM
|
订购信息 Ordering Information
| 产品 |
状况 |
Compliance |
具体说明 |
封装 |
MSL* |
容器 |
预算价格 (1千个数量的单价） |
| 类型 |
外形 |
类型 |
数量 |
| NOIL2SC1300A-GDC |
Active |
|
High Speed CMOS Image Sensor, Color, with Glass |
CPGA-168 |
107DH |
|
Tray JEDEC |
18 |
|
| NOIL2SM1300A-GDC |
Active |
|
High Speed CMOS Image Sensor, Mono, with Glass |
CPGA-168 |
107DH |
|
Tray JEDEC |
18 |
|
数据资料DataSheet下载
