LV56801PGEVB:EVABOARD FOR LV56801P
The LV56801P is a multi-power supply system IC that provides four regulator outputs and two high side switches as well as a number of protection functions including overcurrent protection, overvoltage protection and overheat protection. It is an optimal power supply IC for car audio and car entertainment systems and similar products.
特性 |
LC01707PLFGEVB 实物图 |
评估板信息
| 评估板 | 状况 | 无铅(Pb-free) | 简短说明 | 所用产品 |
|---|---|---|---|---|
| LV56801PGEVB | Active |  |
EVABOARD FOR LV56801P | LV56801P-E |
技术文档
| 类型 | 文档标题 | 文档编号 | 修订号 |
| Eval Board: BOM | LV56801PGEVB Bill of Materials ROHS Compliant | LV56801PGEVB_BOM_ROHS.PDF | 0 |
| Eval Board: Gerber | LV56801PGEVB Gerber Layout Files (Zip Format) | LV56801PGEVB_GERBER.ZIP | 0 |
| Eval Board: Schematic | LV56801PGEVB Schematic | LV56801PGEVB_SCHEMATIC.PDF | 0 |
| Eval Board: Test Procedure | LV56801PGEVB Test Procedure | LV56801PGEVB_TEST_PROCEDURE.PDF | 0 |
