VITA1300:CMOS Image Sensor, Global Shutter, 1.3 Megapixel

The VITA 1300 is a half inch Super eXtended Graphics Array CMOS image sensor with a pixel array of 1280 by 1024. The high sensitivity 4.8 µm x 4.8 µm pixels support pipelined and triggered global shutter readout modes and can be operated in a low noise rolling shutter mode. In rolling shutter mode, the sensor supports correlated double sampling readout, reducing noise and increasing the dynamic range.

技术特性 True family concept Multiple shutter modes High configurability Fast adaptability Multiple windowing High dynamic range

封装图 MARKING DIAGRAM

订购信息 Ordering Information

产品	状况	Compliance	具体说明	封装		MSL*	容器		预算价格 (1千个数量的单价）
				类型	外形		类型	数量
NOIV1SE1300A-QDC	Active	Pb-free Halide free	CMOS Image Sensor, Global Shutter, 1.3 Megapixel, 150 FPS, LVDS Interface, Color, Micro Lens	LCC-48	115AO	3	Tray JEDEC	64
NOIV1SN1300A-QDC	Active	Pb-free Halide free	CMOS Image Sensor, Global Shutter, 1.3 Megapixel, 150 FPS, LVDS Interface, Mono, Micro Lens	LCC-48	115AO	3	Tray JEDEC	64
NOIV1SN1300A-XXC	Active	Pb-free Halide free	CMOS Image Sensor, Global Shutter, 1.3 Megapixel, 150 FPS, Mono, Micro Lens, Die	NA-Bare Die			Tray Foam	9	$119.997
NOIV2SE1300A-QDC	Active	Pb-free Halide free	CMOS Image Sensor, Global Shutter, 1.3 Megapixel, 37 FPS, CMOS Interface, Color, Micro Lens	LCC-48	115AO	3	Tray JEDEC	64
NOIV2SN1300A-QDC	Active	Pb-free Halide free	CMOS Image Sensor, Global Shutter, 1.3 Megapixel, 37 FPS, CMOS Interface, Mono, Micro Lens	LCC-48	115AO	3	Tray JEDEC	64

数据资料DataSheet下载

概述	文档编号/大小	版本
CMOS Image Sensor, Global Shutter, 1.3 Megapixel	VITA1300-D(417.0kB)	1
