AAT3698 1.6A Linear Li-Ion Battery Charger in a 3x3 TDFN Pa
The AAT3698-1/-2 BatteryManager™ is a single-cell lithium- ion (Li-Ion)/Li-Polymer battery charger IC designed to operate from a USB port or AC adapter with an input voltage of up to 7.0V. For increased safety, the AAT3698- 1/-2 also includes over-voltage input protection (OVP) up to 28V. The AAT3698-1/-2 precisely regulates battery voltage for 4.2V Li-Ion/Polymer battery cells through a low RDS(ON) switch. The charging current can be set by an external resistor up to 1.6A. If an over-voltage condition occurs from the input, the series switch quickly opens and a fault flag is activated, preventing damage to the battery and the charging circuitry. Other fault conditions are monitored in real time. In case of an over-current, battery over-voltage, short circuit, or over-temperature failure, the device will automatically shut down, thus protecting the charging device, control system, and the battery under charge. A status monitoring output pin (STAT) is provided to indicate charging activity. This open drain output pin can be used to drive an external LED as a charging indicator. The AAT3698-1/-2 also includes a 5.0V LDO linear regulator with over-voltage protection that can supply loads of up to 50mA. The AAT3698-1/-2 is available in the Pb-free, thermally enhanced, space-saving 3x3mm TDFN33-14 package and is rated over the -40°C to +85°C temperature range.
技术特性
|
订购信息 Ordering Information
应用领域 APPLICATION
功能框图 Functional Block Diagram
|
| 应用技术支持与电子电路设计开发资源下载 | 版本信息 | 大小 |
| AAT3698 数据资料DataSheet下载:pdf | Rev.V2 | 2 页 |
