SKY65131 WLAN Power Amplifier Module
The SKY65131 is a 2.4 GHz power amplifier designed for use in the 2.4 GHz ISM band for wireless LAN applications. The device incorporates a power detector for closed loop monitoring of the output power. The SKY65131 is enabled by a 2.85V reference. The SKY65131 temperature compensated power detector is highly immune to mismatch at its output with less than 1.5 dB of variation with a 2:1 mismatch.
技术特性
- Single 3.3 V supply
- Linear output power of +28 dBm for IEEE802.11b mask
- Linear output power of +26 dBm for IEEE802.11g mask
- High PAE of 38 percent
- Output power detector: 20 dB dynamic range
- Superior gain flatness
- Internal RF match and bias circuits
- Small MCM (16-pin, 4 x 4 mm), Pb-free SMT package (MSL3,
250 °C per JEDEC J-STD-020)
- PA shutdown control
订购信息 Ordering Information
| SKY65131 WLAN Power Amplifier Module |
SKY65131-21 |
TW13-D341 |
|
应用领域 APPLICATION
- IEEE802.11 b/g WLAN
- ISM band transmitters
- WCS fixed wireless
- Wireless access nodes
功能框图 Functional Block Diagram
|
