SKY73103-11 1460-1665 MHz High Performance VCO/Synthesizer With Integrated Switch

SKYWORKS SKY73103-11 Voltage-Controlled Oscillator (VCO)/Synthesizer is a fully integrated, high performance signal source for high dynamic range transceivers. The device provides ultra-fine frequency resolution, fast switching speed, and low phase noise performance for 2G, 2.5G, and 3G base station transceivers. The SKY73103-11 VCO/Synthesizer is a key building block for high-performance radio system designs that require low power and a fine step size. Reference clock generators with an output frequency up to 52 MHz can be used with the SKY73103-11. The input clock frequency is divided down by programmable dividers (1 to 8) for the synthesizer. The phase detector can operate at a maximum speed of 26 MHz, which allows better phase noise due to the lower division value.

技术特性

Wideband frequency operation: 1460 to 1665 MHz
Process-tolerant compensation for VCO
24-bit 􀀶􀀧 fractional-N synthesizer
Ultra-fine frequency resolution of 0.001 ppm
Flexible reference frequency selection
Three-wire serial interface up to 20 MHz clock frequency
Integrated PLL supply regulation for spur isolation
MCM (38-pin, 9 x 12 mm) SMT package (MSL3, 260 􀁱C per
JEDEC J-STD-020)

订购信息 Ordering Information

SKY73103-11

应用领域 APPLICATION

2G, 2.5G, and 3G base station transceivers:
GSM, EDGE, CDMA, WCDMA
General purpose RF systems

功能框图 Functional Block Diagram
