技术特性

• Continuous frequency coverage: 0.35 to 6.2 GHz

• Integer-N frequency synthesizer

• Low phase noise VCO

• Four integrated VCOs with automatic digital frequency calibration

• Automatic VCO selection based on the target RF output

• Programmable VCO division by 1, 2, 3, 4, or 8

• VCO divide-by-three with 50% duty cycle

• Integrated input/output RF buffer

• Device provides both divided and direct VCO outputs

• Programmable RF output power levels

• Low RF output comparison spurs

• Programmable 18-bit N-counter and 11-bit R-counter

• Dual modulus 7 GHz prescaler (selectable 16/17 or 32/33)

• Programmable charge pump current

• Flexible configuration allows connection to external VCO or PLL

• Bidirectional read/write three-wire serial to parallel interface

• Digital lock detect

• Digital output used as a loop filter component switch

• Optional adjustment of the core, divider, and charge pump
  current by external resistor

• Power supply: 3.3 V

• Small, RFLGA (32-pin, 5 x 5 mm) package (MSL3, 260 °C per
  JEDEC J-STD-020)

订购信息 Ordering Information

• SKY73134-11

应用领域 APPLICATION

• Cellular base station systems: GSM/EDGE, CDMA2000, WCDMA,
  TD-SCDMA, LTE

• Other wireless communication systems

功能框图 Functional Block Diagram
