Surface_Mount_Mixer and Detector Schottky Diodes

The Surface_Mount_Mixer is a single-junction circulator designed for radar and Power Amplifier (PA) applications. It operates over the frequency range of 1350 MHz to 1850 MHz. Insertion loss is less than 0.50 dB over an operating temperature range of –40 °C to +100 °C. The Surface_Mount_Mixer comes in an industry-recognized package designed for drop-in assembly.

技术特性
  • Tight parameter distribution
  • Available as singles, pairs, and dual pairs
  • Packages rated MSL1, 260 °C per JEDEC J-STD-020)
应用领域 APPLICATION
  • Sensitive RF and microwave detector circuits
  • Sampling and mixer circuits
  • High-volume wireless
  • WiFi and mobile
  • Low-noise receivers in high-sensitivity ID tags
  • Radio designs
订购信息 Ordering Information
  • Surface_Mount_Mixer
Surface_Mount_Mixer 实物图

Surface_Mount_Mixer 实物图

应用技术支持与电子电路设计开发资源下载 版本信息 大小
Surface_Mount_Mixer 数据资料DataSheet下载:pdf Rev.V2 2 页
