SP6201 微功耗200mA CMOS LDO调节器
The SP6200 and SP6201 are CMOS Low Dropout (LDO) regulators designed to meet a broad range of applications that require accuracy, speed and ease of use. These LDOs offer extremely low quiescent current which only increases slightly under load, thus providing advantages in ground current performance over bipolar LDOs. The LDOs handle an extremely wide load range and guarantee stability with a 1μF ceramic output capacitor. They have excellent low frequency Power Supply Rejection Ratio (PSRR), not found in other CMOS LDOs and thus offer exceptional Line Regulation. High frequency PSRR is better than 40dB up to 400kHz. Load Regulation is excellent and temperature stability is comparable to bipolar LDOs. An enable feature is provided on all versions.
技术特性
- 低压差：160mV@100mA；
- 高输出电压精确度：2%；
- 极低的关断电流：最大为1uA；
- 极低的对地电流：
*200uA@200mA负载；
*28uA@100uA负载；
- 极好的负载和线性调整度；
- 电流和发热限制；
- 复位输出(VOUT良好)；
- 逻辑控制的电子使能；
- 1uF的陶瓷电容可保持器件无条件稳定工作；
- 固定的输出：*5V,1.8V,2.5V,2.7V,2.85V,3.0V,3.3V,3.5V,5V；
- 输出电压可调节。小型DFN封装(2mm×3mm)
- 欲订购无铅封装，请在型号后加“-L”
- 欲订购无卤素绿色封装，请在型号后加“-G”
技术指标
| 输出电流(mA) |
200 |
| 最低输入电压(V) |
2.5 |
| 最高输入电压(V) |
7 |
| 静态电流(µA) |
28 |
| 精确性 |
2% |
| 漏失电压 |
320 |
| 输出电压1.2V |
False |
| 输出电压1.5V |
是 |
| 输出电压1.8V |
是 |
| 输出电压2.0V |
否 |
| 输出电压2.5V |
是 |
| 输出电压2.7V |
是 |
| 输出电压2.85V |
是 |
| 输出电压2.8V |
否 |
| 输出电压3.0V |
是 |
| 输出电压3.3V |
是 |
| 输出电压3.5V |
否 |
| 输出电压5.0V |
是 |
| 输出电压可调 |
是 |
应用领域 APPLICATION
- 移动电话
- 笔记本/掌上电脑
- 电池供电的设备
- 消费者/个人电子产品
- SMPS后置调节器
- DC-to-DC模块
- 医疗器材
- 数据电缆
- 寻呼机
功能框图 Functional Block Diagram
|
订购信息 Ordering Information
| 器件型号 |
有害物质限制 |
最低温度 |
最高温度 |
状态 |
申请样片 |
| SP6201ER-2-85/TR |
|
|
|
返修 |
|
| SP6201ER-3-0 |
|
|
|
返修 |
|
| SP6201ER-2-85 |
|
-40 |
125 |
返修 |
|
| SP6201ER-2-7 |
|
|
|
返修 |
|
| SP6201ER-2-7/TR |
|
|
|
返修 |
|
| SP6201ER-3-5 |
|
|
|
返修 |
|
| SP6201ER-3-5/TR |
|
|
|
返修 |
|
| SP6201ER-3-3/TR |
|
|
|
运行 |
|
| SP6201ER-3-0/TR |
|
|
|
返修 |
|
| SP6201ER-3-3 |
|
-40 |
125 |
运行 |
|
| SP6201ER-2-5/TR |
|
|
|
返修 |
|
| SP6201ER |
|
|
|
OBS |
|
| SP6201ER/TR |
|
|
|
返修 |
|
| SP6201EM5-L-5-0/TR |
|
-40 |
125 |
运行 |
|
| SP6201EM5-L-3-5/TR |
|
|
|
返修 |
|
| SP6201EM5-L-5-0 |
|
-40 |
125 |
运行 |
|
| SP6201ER-1-8 |
|
|
|
OBS |
|
| SP6201ER-2-5 |
|
-40 |
125 |
返修 |
|
| SP6201ER-1-5 |
|
|
|
返修 |
|
| SP6201ER-1-8/TR |
|
-40 |
125 |
OBS |
|
| SP6201ER-1-5/TR |
|
|
|
返修 |
|
| SP6201ER-5-0 |
|
|
|
返修 |
|
| SP6201ER-L-3-3 |
|
-40 |
125 |
运行 |
|
| SP6201ER-L-2-85/TR |
|
-40 |
125 |
EOL |
|
| SP6201ER-L-3-0 |
|
-40 |
125 |
EOL |
|
| SP6201ER-L-3-0/TR |
|
-40 |
125 |
EOL |
|
| SP6201EK |
|
-40 |
125 |
OBS |
|
| SP6201ER-L-2-85 |
|
-40 |
125 |
EOL |
|
| SP6201ER-L-5-0 |
|
-40 |
125 |
EOL |
|
| SP6201ER-L-3-5/TR |
|
|
|
返修 |
|
| SP6201ER-L-3-3/TR |
|
-40 |
125 |
运行 |
|
| SP6201ER-L-3-5 |
|
|
|
返修 |
|
| SP6201ER-L-2-7/TR |
|
|
|
返修 |
|
| SP6201ER-L-1-5 |
|
-40 |
125 |
EOL |
|
| SP6201ER-L-1-5/TR |
|
-40 |
125 |
EOL |
|
| SP6201ER-L/TR |
|
-40 |
125 |
返修 |
|
| SP6201ER-5-0/TR |
|
|
|
返修 |
|
| SP6201ER-L |
|
-40 |
125 |
返修 |
|
| SP6201ER-L-2-5 |
|
-40 |
125 |
EOL |
|
| SP6201ER-L-2-7 |
|
|
|
返修 |
|
| SP6201ER-L-1-8 |
|
-40 |
125 |
返修 |
|
| SP6201ER-L-2-5/TR |
|
-40 |
125 |
EOL |
|
| SP6201ER-L-1-8/TR |
|
-40 |
125 |
返修 |
|
| SP6201EM5-G-3-3 |
|
-40 |
125 |
Active |
|
| SP6201EM5-G-3-3/TR |
|
-40 |
125 |
Active |
|
| SP6201EM5-ADJ/TR |
|
-40 |
125 |
运行 |
|
| SP6201EM5-L-1-5 |
|
-40 |
125 |
运行 |
|
| SP6201EM5-L/TR |
|
-40 |
125 |
运行 |
|
| SP6201EM5-L |
|
-40 |
125 |
运行 |
|
| SP6201EM5-ADJ |
|
-40 |
125 |
运行 |
|
| SP6201EM5-2-7/TR |
|
|
|
运行 |
|
| SP6201EM5-1-8/TR |
|
-40 |
125 |
运行 |
|
| SP6201EM5 |
|
-40 |
125 |
运行 |
|
| SP6201ER-L-5-0/TR |
|
-40 |
125 |
EOL |
|
| SP6201EM5-3-3 |
|
-40 |
125 |
运行 |
|
| SP6201EM5-3-0/TR |
|
-40 |
125 |
运行 |
|
| SP6201EM5-L-1-5/TR |
|
-40 |
125 |
运行 |
|
| SP6201EM5-2-5/TR |
|
-40 |
125 |
OBS |
|
| SP6201EM5-2-7 |
|
|
|
OBS |
|
| SP6201EM5-3-0 |
|
|
|
OBS |
|
| SP6201EM5-L-3-3 |
|
-40 |
125 |
运行 |
|
| SP6201EM5-2-5 |
|
|
|
OBS |
|
| SP6201EM5-2-85 |
|
|
|
OBS |
|
| SP6201EM5-2-85/TR |
|
-40 |
125 |
OBS |
|
| SP6201EK/TR |
|
-40 |
125 |
OBS |
|
| SP6201EM5-L-3-5 |
|
-40 |
125 |
返修 |
|
| SP6201EM5-L-3-3/TR |
|
-40 |
125 |
运行 |
|
| SP6201EM5/TR |
|
-40 |
125 |
OBS |
|
| SP6201EM5-1-5 |
|
|
|
OBS |
|
| SP6201EM5-1-5/TR |
|
-40 |
125 |
OBS |
|
| SP6201EM5-1-8 |
|
|
|
OBS |
|
| SP6201EM5-L-2-5/TR |
|
-40 |
125 |
运行 |
|
| SP6201EM5-L-2-7 |
|
-40 |
125 |
运行 |
|
| SP6201EM5-L-2-7/TR |
|
-40 |
125 |
OBS |
|
| SP6201EM5-L-2-5 |
|
-40 |
125 |
运行 |
|
| SP6201EM5-5-0/TR |
|
-40 |
125 |
OBS |
|
| SP6201EM5-L-1-8 |
|
-40 |
125 |
运行 |
|
| SP6201EM5-L-1-8/TR |
|
-40 |
125 |
运行 |
|
| SP6201EM5-L-2-85 |
|
-40 |
125 |
运行 |
|
| SP6201EM5-3-3/TR |
|
-40 |
125 |
OBS |
|
| SP6201EM5-L-3-0 |
|
-40 |
125 |
运行 |
|
| SP6201EM5-L-3-0/TR |
|
-40 |
125 |
运行 |
|
| SP6201EM5-3-5 |
|
|
|
OBS |
|
| SP6201EM5-L-2-85/TR |
|
-40 |
125 |
运行 |
|
