技术特性

• 24 to 43 GHz high isolation SPDT
• < 2 dB typical insertion loss
• -10 dB typical return loss
• On-chip bias resistors
• Flexible bias pad configuration
• Reflective switch design
• Integrated DC blocks on RF pads
• Dimensions: 2.164 x 1.055 x 0.1 mm (2.283 mm²)

技术指标

订购信息 Ordering Information

• TGS4301

应用领域 APPLICATION

• Ka Band VSAT
• LMDS
• Point-to-Multipoint Radio
• Point-to-Point Radio

机械图样Mechanical Drawing
